Panasonic SA-VKX95EE - Mic and Panel PCB Voltage Measurements

95
14.1.9. Main P.C.B. Ass'y (5/5) , Mic & Panel P.C.B.
REF NO.
MODE E C B E C B E C B E C B E C B
PLAY 0 3.2 0 5.5 0 5.1 0 0 3.1 0 0 0 0 0 3.2
STANDBY 0 3.2 0 5.5 0 5.1 0 0 3.1 0 0 0 0 0 3.2
REF NO.
MODE E C B E C B E C B
PLAY 0 0 0 0 12.2 0 0 6.2 0
STANDBY 0 0 0 0 12.2 0 0 6.2 0
REF NO.
MODE 1234567891011121314
PLAY 6.2 6.2 6.2 6.2 6.2 6.3 6.3 0 12.3 6.1 0.2 0 12.3 6.2
STANDBY 6.2 6.2 6.2 6.2 6.2 6.3 6.3 0 12.3 6.1 0.2 0 12.3 6.2
REF NO.
MODE 1234567891011121314
PLAY 6.2 6.2 6.1 6.1 6.1 6.2 6.2 0 12.3 6.1 0.2 0 12.3 6.1
STANDBY 6.2 6.2 6.1 6.1 6.1 6.2 6.2 0 12.3 6.1 0.2 0 12.3 6.1
REF NO.
MODE 1234567891011121314151617181920
PLAY 00001.93.31.302.90003.3-15.9 -15.9 -19.6 -23.3 -21.4 -23.3 -21.4
STANDBY 00001.93.31.302.90003.3-15.9 -15.9 -19.6 -23.3 -21.4 -23.3 -21.4
REF NO.
MODE 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
PLAY -23.3 -23.3 -21.4 -23.3 -15.9 -19.6 -15.9 -21.4 -23.3 -23.7 -22 -21.6 -21.4 -21.4 -21.4 -21.4 -21.4 -21.4 -21.4 -21.4
STANDBY -23.3 -23.3 -21.4 -23.3 -15.9 -19.6 -15.9 -21.4 -23.3 -23.7 -22 -21.6 -21.4 -21.4 -21.4 -21.4 -21.4 -21.4 -21.4 -21.4
REF NO.
MODE 41 42 43 44
PLAY -21.5 -21.8 3.3 0
STANDBY -21.5 -21.8 3.3 0
REF NO.
MODE E C B E C B E C B E C B E C B
PLAY 1.7 4.8 2.1 0 15.5 -0.2 0 4 0 0 3.8 0 0 3 0
STANDBY 1.7 4.8 2.1 0 15.5 -0.2 0 4 0 0 3.8 0 0 3 0
REF NO.
MODE E C B
PLAY 0 0 3.2
STANDBY 0 0 3.2
QR2503
QR2505 QR6101 QR9002
Q3503 Q9004 QR2102 QR2502
IC6000
Q6000 Q6001 QR6000 QR6003 QR6004
SA-VKX95GA/GS/EE MIC P.C.B
.
IC6000
IC6000
SA-VKX95GA/GS/EE MAIN P.C.B. ASS'Y
IC1400
IC1401
SA-VKX95GA/GS/EE PANEL P.C.B
.
QR6005
