16
RQT9666
≥For a safety measure to prevent the speakers from falling, refer to page 17.
≥To prevent damage or scratches, lay down a soft cloth and perform the assembly on it.
Assemble the speakers following step 1 of “Place the speakers
vertically” (> 12).
Insert the speaker cable through the base.
≥ Be sure to insert the speaker cable through the threading hole as indicated in the illustration. (If the speaker cable is
twisted, it might not fit through the opening. Straighten the speaker cable before inserting.)
Attach the speaker to the base.
≥ The two speakers are interchangeable.
≥ Keep the screws out of reach of children to prevent swallowing.
Place the speakers using the speaker
bases
∏ 2 Speakers ∏ 2 Speaker cables
(L): WHITE
(R): RED
∏ 2 Bases
∏ 2 Front ornaments ∏ 6 Screws
A Threading hole B Screw hole
To Next Page
