16
RQT7357
Listening operations
Cassette tapes
1 Press [OPEN 0] to insert a cassette with the tape
facing in.
When the button is pressed, the unit comes on
automatically. Make sure the cassette is fully inserted and
close the lid by hand.
2 Press [TAPE 3] to start playback.
One side is played, then playback stops automatically. To
play on the other side of the cassette, turn the cassette
over and press [TAPE 3].
3 Adjust the volume.
Cassette tape selection and care
Types of cassettes which can be played correctly
Only normal position tapes are recommended.
NORMAL POSITION/TYPE I ✓
HIGH POSITION/TYPE II ✕
METAL POSITION/TYPE IV ✕
• Tapes exceeding 100 minutes are thin and can break or get
caught in the mechanism.
• Tape slack can get caught up in the mechanism and should
be wound up before the tape is played.
• Endless tapes can get caught up in the deck’s moving parts
if used incorrectly.
To find the beginning of a program
(TPS: Tape Program Sensor)
TPS finds the beginning of a track and resumes play from there.
Each press increases the number of tracks skipped, up to a
maximum of 9.
Press [
44
44
4/REW/4] or [
33
33
3/FF/¢] during play.
Notes
The TPS function searches for silent parts of about 4 seconds
in length which are normally found between tunes. As a result,
it may not function properly in the following cases:
• With short silent parts
• When noise occurs between tunes
• With silent parts found within tunes
3
2
//
REW
,
//
FF
STOP ,
1
–DEMO
1
OPEN
B
O
P
E
N
2
TAPE
3
To
stop tape playback
start one touch play
fast-forward and
rewind
Action
Press [STOP 7, –DEMO].
Press [TAPE 3] when the system is
OFF with the cassette loaded.
Press [
44
44
4/REW/4] or [
33
33
3/FF/¢] in
the stop mode.
Top of the unit
Insert inside
the guides
Forward side
RQT7357-C_13-16_EN 10/1/04, 2:53 pm16
