SB-TM23 Service Manual
1 Connection of the Speaker Cables
· Be sure to connect speaker cables before
connecting the AC power supply cord.
· The load impedance of any speaker used with
this unit must be 5Ω.
· Be sure to connect the cable from the right
speaker to the right terminal and the cable from the left
speaker to the left terminal.
Strip off the outer covering, and twist the center conduc-
tor. Make sure the bare ends of the wires are not
unravelled. (If they are, twist them tight again.)
Insert the wire to the rear panel of the unit and close the
lever.
Notes :
· To prevent damage to circuitry, never short-
circuit positive (+) and negative (-) speaker wires.
· Be sure to connect only positive (red) wires to
positive (+) terminals and negative (black) wires to
negative (-) terminals.
Placement
Place the front speakers so that the super tweeter is on
the inside.
Notes :
· Keep your speakers at least 10 mm (13/32”) away
from the system for proper ventilation.
· These speakers do not have magnetic shielding.
Do not place them near televisions, personal computers
or other devices easily influenced by magnetism.
· You cannot take the front net off the speakers.
Connection
Use only the supplied speakers.
The combination of the main unit and speakers provide the
best sound.
Using other speakers can damage the unit and sound
quality will be negatively affected.
Notes on speaker use
· You can damage your speakers and shorten their
useful life if you play sound at high levels over extended
periods.
· Reduce the volume in the following cases to avoid
damage.
· When playing distorted sound.
· When adjusting the sound quality.
