23.4 Electrical Parts List
Ref. No. Part No. Part Name & Description
REPM05230A CONJUNTO MANUAL TRANSFORMADOR SC-TM23
RENM05230A CONJUNTO RADIAL TRANSFORMADOR SC-TM23
RENM05230AZ CONJUNTO AXIAL TRANSFORMADOR SC-TM23
RENM05230AJ CONJUNTO JUMPER TRANSFORMADOR SC-TM23
REPM05231A CONJUNTO MANUAL PODER SC-TM23
RENM05231A CONJUNTO RADIAL PODER SC-TM23
RENM05231AZ CONJUNTO AXIAL PODER SC-TM23
RENM05231AJ CONJUNTO JUMPER PODER SC-TM23
REPM05232A CONJUNTO MANUAL MAIN SC-TM23
REAM05232A CONJUNTO SMT MAIN SC-TM23
RENM05232A CONJUNTO RADIAL MAIN SC-TM23
RENM05232AZ CONJUNTO AXIAL MAIN SC-TM23
RENM05232AJ CONJUNTO JUMPER MAIN SC-TM23
RENM03815A CONJUNTO TUNER PACK RADIAL
RENM03815AZ CONJUNTO TUNER PACK AXIAL
RENM03815AJ CONJUNTO TUNER PACK JUMPER
REPM05233A CONJUNTO MANUAL PANEL SC-TM23
RENM05233A CONJUNTO RADIAL PANEL SC-TM23
RENM05233AZ CONJUNTO AXIAL PANEL SC-TM23
RENM05233AJ CONJUNTO JUMPER PANEL SC-TM23
CAPACITORS
C5961 ECA1AM471B CAPACITOR ELECTROLITICO
C5962 ECA1AM471B CAPACITOR ELECTROLITICO
C5957 ECA1HM100B C.ELECTROLITICO
C5956 F2A1H470A147 CAPACITOR
C5952 F2A1A470A011 CAPACITOR
C5963 ECEA1VKA4R7B CAPACITOR ELECTROLITICO
C5951 F1B1H1030003 CAPACITOR
C5954 F1B1H1030003 CAPACITOR
C5959 F1B1H1030003 CAPACITOR
C5960 ECQE2104KF3 CAPACITOR PP
C5958 F1B1H1030003 CAPACITOR
C5953 F1B1H1030003 CAPACITOR
C5955 ECA1HM220B C.ELECTROLITICO
C5950 ECA1EM222B CAPACITOR
C5810 F2A1E101A122 CAPACITOR
C5807 F2A1C100A196 CAPACITOR
C5808 F2A1C100A196 CAPACITOR
C5813 ECEA1EKA100B CAPACITOR ELECTROLITICO
C5812 ECEA1EKA330B CAPACITOR ELECTROLITICO
C5803 F1D1H101A012 CAPACITOR CERAMICO
C5501 F1D1H103A046 CAPACITOR
C5243 ECBT1H150J5 CAPACITOR
C5441 ECBT1H150J5 CAPACITOR
