Ref.

No.

Part No. Part Name & Description Remarks

Q4305 2SB1218ARL TRANSISTOR SI PNP CHIP (

J,K,L )

Q4306 UNR9112J08 TRANSISTOR SI PNP CHIP (

J,K,L )

Q4306

B1GDCFLL0019 TRANSISTOR SI PNP CHIP (

J,K,L )

Q4306

B1GDCFLL0020 TRANSISTOR SI PNP CHIP (

J,K,L )

Q4307 UNR9213J08 TRANSISTOR SI NPN CHIP (

J,K,L )

Q4307

B1GBCFNN0029 TRANSISTOR SI NPN CHIP (

J,K,L )

Q4307

B1GBCFNN0030 TRANSISTOR SI NPN CHIP (

J,K,L )

Q4801 2SD2216J08 TRANSISTOR SI NPN CHIP 1

Q4801

B1ABCF000104 TRANSISTOR SI NPN CHIP 1

Q4801

B1ABCF000110 TRANSISTOR SI NPN CHIP 1

Q6501 B1ABCF000098 TRANSISTOR SI NPN CHIP 1

Q6501

B1ABCF000099 TRANSISTOR SI NPN CHIP 1

Q6502 2SB1218AHL TRANSISTOR SI PNP CHIP 1

Q6502

B1ADCF000063 TRANSISTOR SI PNP CHIP 1

Q6502

B1ADCF000075 TRANSISTOR SI PNP CHIP 1

Q7801 XP0450100L TRANSISTOR COMPLX CMP SI NPN

CHIP

Q7801

B1HBCFA00011 TRANSISTOR COMPLX CMP SI NPN

CHIP

Q7801

B1HBCFA00016 TRANSISTOR COMPLX CMP SI NPN

CHIP

DIODES

Ref.

No.

Part No. Part Name & Description Remarks

D4301 B3AFB0000171 LIGHT EMITTING DIODE ( J,K,L

)

D6503 B0ADEJ000038 DIODE SI CHIP 1

D6504 B3GA00000062 INFRARED SENSOR 1

RESISTORS

Ref.

No.

Part No. Part Name & Description Remarks

R4301 ERJ6GEYJ270V MGF CHIP 1/10W 27 ( J,K,L ) 1

R4302 ERJ6GEYJ270V MGF CHIP 1/10W 27 ( J,K,L ) 1

R4303 ERJ3GEYJ2R2V MGF CHIP 1/16W 2.2 ( J,K,L ) 1

R4305 ERJ2RHD222X MGF CHIP 1/16W +-0.5% ( J,K,L

)

R4306 ERJ2RHD183X MGF CHIP 1/16W 18K ( J,K,L ) 1

R4307 ERJ2RHD472X MGF CHIP 1/16W 4.7K ( J,K,L ) 1

R4308 ERJ2RHD222X MGF CHIP 1/16W +-0.5% ( J,K,L

)

R4310 ERJ6GEYJ270V MGF CHIP 1/10W 27 ( J,K,L ) 1

R4311 ERJ6GEYJ270V MGF CHIP 1/10W 27 ( J,K,L ) 1

R4802 D0GA472JA015 MGF CHIP 1/16W 4.7K 1

R4803 D0GA223JA015 MGF CHIP 1/16W 22K 1

R4804 D0GA333JA015 MGF CHIP 1/16W 33K 1

R4805 ERJ2GEJ124X MGF CHIP 1/16W 120K 1

R4806 D0GA333JA015 MGF CHIP 1/16W 33K 1

R4807 D0HB392ZA002 MGF CHIP 1/16W 3.9K 1

R4808 ERJ2GEJ124X MGF CHIP 1/16W 120K 1

R4809 D0GA333JA015 MGF CHIP 1/16W 33K 1

R4810 D0HB392ZA002 MGF CHIP 1/16W 3.9K 1

R6503 ERJ2GEJ104X MGF CHIP 1/16W 100K 1

R6504 ERJ2GEJ106X MGF CHIP 1/16W 10M 1

R6505 ERJ3GEYJ335V MGF CHIP 1/16W 3.3M 1

R6506 ERJ2GEJ184X MGF CHIP 1/16W 180K 1

R6507 D0GA103JA015 MGF CHIP 1/16W 10K 1

R6509 D0GA102JA015 MGF CHIP 1/16W 1K 1

R7801 D0GA392JA015 MGF CHIP 1/16W 3.9K 1

R7802 D0GA392JA015 MGF CHIP 1/16W 3.9K 1

R7803 D0GA332JA015 MGF CHIP 1/16W 3.3K 1

R7804 D0GA332JA015 MGF CHIP 1/16W 3.3K 1

R7805 D0GA102JA015 MGF CHIP 1/16W 1K 1

R7806 D0GA102JA015 MGF CHIP 1/16W 1K 1

R7807 D0GA103JA015 MGF CHIP 1/16W 10K 1

Ref.

No.

Part No. Part Name & Description Remarks

R7808 ERJ2GEJ394X MGF CHIP 1/16W 390K 1

R7809 ERJ2GEJ394X MGF CHIP 1/16W 390K 1

R7810 D0GA472JA015 MGF CHIP 1/16W 4.7K 1

R7811 D0GA472JA015 MGF CHIP 1/16W 4.7K 1

R7814 ERJ2GEJ274X MGF CHIP 1/16W 270 +-5% 1

R7815 ERJ2GEJ274X MGF CHIP 1/16W 270 +-5% 1

CAPACITORS

Ref.

No.

Part No. Part Name & Description Remarks

C4301 F1H1A105A036 C CHIP 10V 1UF ( J,K,L ) 1

C4801 F1G0J1050007 C CHIP 6.3V 1UF 1

C4802 F1G0J1050007 C CHIP 6.3V 1UF 1

C4803 F1J0J106A004 C CHIP 6.3V 10UF 1

C4804 ECJ0EB1C822K C CHIP 16V 8200PF 1

C4805 ECJ0EB1A273K C CHIP 10V 0.027UF 1

C4806 ECJ0EB1A273K C CHIP 10V 0.027UF 1

C4808 ECJ0EB1A273K C CHIP 10V 0.027UF 1

C4809 ECJ0EB1C822K C CHIP 16V 8200PF 1

C4810 ECJ0EB1A273K C CHIP 10V 0.027UF 1

C4812 F3F0J226A032 TANTALUM CHIP 6.3V 22UF 1

C6503 F1H1A224A012 C CHIP 10V 0.22UF 1

C6504 F1G1A1040006 C CHIP 10V 0.1UF 1

C6505 F1H1A224A012 C CHIP 10V 0.22UF 1

C7801 F1J1A106A024 C CHIP 10V 10UF 1

C7802 F1J1A106A024 C CHIP 10V 10UF 1

C7803 F3F0J226A032 TANTALUM CHIP 6.3V 22UF 1

C7804 F3F0J226A032 TANTALUM CHIP 6.3V 22UF 1

C7805 F1G1C153A048 C CHIP 16V 0.015UF 1

C7806 F1G1C153A048 C CHIP 16V 0.015UF 1

C7807 F1G1C153A048 C CHIP 16V 0.015UF 1

C7808 F1G1C153A048 C CHIP 16V 0.015UF 1

C7809 F1J1A106A024 C CHIP 10V 10UF 1

C7810 F1J1A106A024 C CHIP 10V 10UF 1

C7811 F1J1A106A024 C CHIP 10V 10UF 1

C7812 F1J1A106A024 C CHIP 10V 10UF 1

C7813 F1G1H222A571 C CHIP 50V 2200PF 1

C7814 F1G1H222A571 C CHIP 50V 2200PF 1

C7815 F1H0J1050012 C CHIP 6.3V 1UF 1

COILS

Ref.

No.

Part No. Part Name & Description Remarks

L7801 G1C100KA0055 COIL CHIP 10UH 1

FPC CONNECTOR

Ref.

No.

Part No. Part Name & Description Remarks

FP6501 K1MN18A00064 CONNECTOR 18P 1

17.3.3. LCD BACKLIGHT P.C.B.

TRANSISTORS

Ref.

No.

Part No. Part Name & Description Remarks

Q8101 2SC6054J0L TRANSISTOR SI NPN CHIP 1

Q8102 2SC6054J0L TRANSISTOR SI NPN CHIP 1

Q8103 2SC6054J0L TRANSISTOR SI NPN CHIP 1

Q8104 2SC6054J0L TRANSISTOR SI NPN CHIP 1

Q8105 2SC6054J0L TRANSISTOR SI NPN CHIP 1

Q8108 2SC6054J0L TRANSISTOR SI NPN CHIP 1

Q8112 2SA2174J0L TRANSISTOR SI PNP CHIP 1

Q8113 2SA2174J0L TRANSISTOR SI PNP CHIP 1

Q8114 UNR9213J08 TRANSISTOR SI NPN CHIP 1

Q8114

B1GBCFNN0029 TRANSISTOR SI NPN CHIP 1

Q8114

B1GBCFNN0030 TRANSISTOR SI NPN CHIP 1

Q8115 UNR9213J08 TRANSISTOR SI NPN CHIP 1

Q8115

B1GBCFNN0029 TRANSISTOR SI NPN CHIP 1

Q8115

B1GBCFNN0030 TRANSISTOR SI NPN CHIP 1

Q8116 UNR9213J08 TRANSISTOR SI NPN CHIP 1

Q8116

B1GBCFNN0029 TRANSISTOR SI NPN CHIP 1
