Panasonic SDR-H20EE - Page 79

17.3.5. SIDE R P.C.B.
TRANSISTORS
Ref.
No.
Part No. Part Name & Description Remarks
Q6301 2SB09700RL TRANSISTOR SI PNP CHIP 1
DIODES
Ref.
No.
Part No. Part Name & Description Remarks
D6301 B3AAB0000137 LIGHT EMITTING DIODE RED 1
RESISTORS
Ref.
No.
Part No. Part Name & Description Remarks
R6301 ERJ3GEYJ680V MGF CHIP 1/16W 68 1
R6302 ERJ3GEYJ680V MGF CHIP 1/16W 68 1
R6303 ERJ3GEYJ680V MGF CHIP 1/16W 68 1
R6304 ERJ3GEYJ680V MGF CHIP 1/16W 68 1
R6305 ERJ3GEYJ680V MGF CHIP 1/16W 68 1
R6311 ERJ3GEY0R00V MGF CHIP 1/16W 0 1
R6312 ERJ3GEY0R00V MGF CHIP 1/16W 0 1
R6313 ERJ3GEY0R00V MGF CHIP 1/16W 0 1
R6314 ERJ3GEY0R00V MGF CHIP 1/16W 0 1
R6315 ERJ3GEY0R00V MGF CHIP 1/16W 0 1
R6323 ERJ3GEYJ561V MGF CHIP 1/16W 560 1
R6324 ERJ3GEY0R00V MGF CHIP 1/16W 0 1
R6325 ERJ6GEYJ150V MGF CHIP 1/10W 15 1
R6326 ERJ3GEY0R00V MGF CHIP 1/16W 0 1
R6327 ERJ3GEY0R00V MGF CHIP 1/16W 0 1
R7001 ERJ6GEYJ122V MGF CHIP 1/10W 1.2K +-5% 1
CAPACITORS
Ref.
No.
Part No. Part Name & Description Remarks
C6301 F3G0J107A017 TANTALUM CHIP 6.3V 100UF 1
C6302 F1H1C104A041 C CHIP 16V 0.1UF 1
C6303 F1H1C104A041 C CHIP 16V 0.1UF 1
C6304 ECJ1VC1H180J C CHIP 50V 18PF 1
C6305 ECJ1VC1H180J C CHIP 50V 18PF 1
C6306 ECJ1VC1H180J C CHIP 50V 18PF 1
C6307 ECJ1VC1H180J C CHIP 50V 18PF 1
C6308 ECJ1VC1H180J C CHIP 50V 18PF 1
C6310 F1H1H103A219 C CHIP 50V 0.01UF 1
C6312 F1H1H103A219 C CHIP 50V 0.01UF 1
C6313 F1H1H103A219 C CHIP 50V 0.01UF 1
C6315 F1H1H103A219 C CHIP 50V 0.01UF 1
C6316 F1H1H103A219 C CHIP 50V 0.01UF 1
C6317 F1H1H103A219 C CHIP 50V 0.01UF 1
C6319 F1H1H103A219 C CHIP 50V 0.01UF ( J,K,L ) 1
COILS
Ref.
No.
Part No. Part Name & Description Remarks
L6301 G1C100KA0031 COIL CHIP 10UH 1
PIN HEADERS
Ref.
No.
Part No. Part Name & Description Remarks
P6301 K1KA02BA0014 CONNECTOR 2P 1
FP6301 K1MN24BA0196 CONNECTOR 24P 1
SWITCHES
Ref.
No.
Part No. Part Name & Description Remarks
SW6301 K0F111A00547 SWITCH PUSH 1
SW6302 K0D113B00087 SWITCH SLIDE 1
SW6303 K0F111A00547 SWITCH PUSH 1
SW6304 K0F111A00547 SWITCH PUSH 1
SW6305 K0L1AA000010 SWITCH SEESAW 1
SW6306 K0F111A00547 SWITCH PUSH ( J,K,L ) 1
17.3.6. OPEN SWITCH P.C.B.
SWITCH
Ref.
No.
Part No. Part Name & Description Remarks
SW8301 K0L1AA000010 SWITCH SEESAW 1
79
SDR-H20E
