19. SPECIFICATIONS
Designation S-LINK gateway controller for DeviceNet
Item Model No. SL-GU1-D
Power supply 24V DC±10%
Current consumption 1.6A or less (Note 1)
Allowable through current 7A (Note 2)
DeviceNet transmis-
Transmission standard
Transmission function Group 2 Only Server, Connection Poll
Address setting 0 to 63
Electrical Charac. ISO 11898 CAN Physical layer
Coding method NRZ
Transmission speed 125kbps, 250kbps, 500kbps
DeviceNet
setting
Address setting Setting with dip switch, 6 bits
Baud Rate Setting with dip switch, 2 bits
S-LINK system side-
output in case of net-
work error
All outputs reset to “OFF” / All outputs maintained can be set.
S-LINK system
transmission
Transmission speed 28.5kbps
Transmission distance Signal main cable: total length 200m max. (with booster: 400m max.)
I/O channel No. Max. 128 I/Os (varies with type of devices used and places connected)
FAN-out 320
No. of branches 10 branches or less
Ambient temperature 0 to +55°C (No dew or ice condensation allowed), Storage: -20 to +75°C
Ambient humidity 35 to 85% RH, Storage: 35 to 85% RH
Weight Approx. 250g
Material Enclosure: ABS
Notes: 1) The current consumption is the sum of the maximum current (D-G line only) supplied to the connected S-
LINK units and the current consumption of SL-GU1-D.
2) The allowable through current is the maximum value of the sum of the above mentioned current consump-
tion and the current consumed by the users’ devices connected to the S-LINK units.
3)
