Single Media Player (Type 3)
Files will be played in the order they were listed in a
scenario.
Scenario and file list
Scenario:
Enter [File definition: Play time].
File list:
Enter [File definition: File name].
Setting example
USB memory contents
filelist.dat
scenario.dat
Contents_Video1.wmv
Contents_Video2.wmv
Contents_Video3.wmv
scenario.dat (scenario)
PHOTO_001:10
VIDEO_001:10
VIDEO_002:20
VIDEO_003:
filelist.dat (file list)
VIDEO_001:Contents_Video1.wmv
VIDEO_002:Contents_Video2.wmv
VIDEO_003:Contents_Video3.wmv
Play contents
For the above setting example, the following contents
will be played on repeat (loop).
1. Introduction.jpg (10 seconds)
2. Contents_Video1.wmv (10 seconds)
3. Contents_Video2.wmv (20 seconds)
4. Contents_Video3.wmv (Played for the
duration of the play
time of the file)
Multi Media Player
Files will be played in the order they were listed in the
scenario for Parent.
Scenario and file list
[Parent side]
Scenario:
Enter [File definition: Play time].
File list - The first line:
Enter [Group ID].
File list - The second and subsequent lines:
Enter [File definition: File name].
[Child side]
Scenario:
Unnecessary
File list - The first line:
Enter [Group ID].
File list - The second and subsequent lines:
Enter [File definition: File name].
Setting example
[Parent side]
USB memory contents
filelist.dat
scenario.dat
L_Contents_Video1.wmv
L_Contents_Video2.wmv
L_Contents_Video3.wmv
scenario.dat (scenario)
PHOTO_001:10
VIDEO_001:10
VIDEO_002:20
VIDEO_003:
filelist.dat (file list)
GroupID:G01
VIDEO_001:L_Contents_Video1.wmv
VIDEO_002:L_Contents_Video2.wmv
VIDEO_003:L_Contents_Video3.wmv
[Child side]
USB memory contents
filelist.dat
R_Contents_Video1.wmv
R_Contents_Video2.wmv
R_Contents_Video3.wmv
filelist.dat (file list)
GroupID:G01
VIDEO_001:R_Contents_Video1.wmv
VIDEO_002:R_Contents_Video2.wmv
VIDEO_003:R_Contents_Video3.wmv
