English
88
LAN
RJ45 × 1:
For RJ45 network connections, compatible with
PJLink
Communication method:
RJ45 10BASE-T/100BASE-TX
IR IN
Stereo mini jack (M3) × 1
IR OUT
Stereo mini jack (M3) × 1
USB
TYPE A USB connector × 1
DC 5V / 1A (USB 3.0 is not supported.)
Sound
Speakers
80 mm × 30 mm × 2 pcs
Audio Output
20 W [10 W + 10 W] (10 % THD)
Remote Control Transmitter
Power source
DC 3 V (battery (AAA/R03/UM4 type) × 2)
Operating range
Approx. 7 m (22.9 ft)
(when operated directly in front of remote control
sensor)
Mass
Approx. 63
/ 2.22 oz (including batteries)
Dimensions (W × H × D)
44 mm × 105 mm × 20.5 mm /
1.74” × 4.14” × 0.81”
*
1: Environmental temperature to use this unit at high
altitudes (1 400 m (4 593 ft) and higher and below
2 800 m (9 186 ft) above sea level): 0 °C to 35 °C
(32 °F to 95 °F)
*
2: VIERA LINK is not supported.
Note
●
Design and specifications are subject to change
without notice. Mass and dimensions shown are
approximate.
