Panasonic TH-50VX100U - 13 Printed Circuit Board; P-Board

TH-50VX100U / TH-50VX100E
99
13 Printed Circuit Board
13.1. P-Board
ABCDEFGH I
1
2
3
4
5
6
P(AC)-BOARD ETX2MM704MGB (FOIL SIDE) P(AC)-BOARD ETX2MM704MGB (COMPONET SIDE)
TH-50VX100U/E
P(AC)-BOARD ETX2MM704MGB
TH-50VX100U/E
P(AC)-BOARD ETX2MM704MGB
Parts Location
P-BOARD (FOIL SIDE)
IC
MODULE
TEST POINT
P-BOARD (COMPONENT SIDE)
IC
MODULE
TEST POINT
IC501
IC555
MC501
TP3
TP4
IC501
IC555
MC501
TP3
TP4
B-5
B-6
C-5
A-5
C-5
E-5
E-6
D-5
F-5
D-5
P(AC)
