Panasonic WJ-HD220

15
SIGNAL GND
POWER
DATA10/100BASE-TMODERS-232C
MULTI
SCREEN OUT
SPOT
OUT
1
1
ALARM/REMOTE
OFF
ON
2
2
3
3
4
4
5
5
6
6
7
7
8
8
OUT
VIDEO
OUT
AUDIO
IN
IN
AC 120 V 60 Hz
POWER
ON
OFF
ALARM
Data Multiplex Unit WJ-MP204
ALARM
SUSPEND
Combination Cameras
Pan/Tilt Table
Receiver
Data Multiplex Unit
Hub/Router
PC (Internet Browser)
PC (Internet Browser)
RS485 Cable
(WV-CA48)
LAN Cable
(10Base-T/100Base-TX
Category 5)
LAN/Internet
Combination Cameras
<Network System>
Personal computers can access the WJ-HD220 via the network.
