CONSTRUCTION
Ensuring Trouble-free Operation
• This camera uses a “slip ring” for transmission of electrical power and signals. A dirty slip ring can cause
deterioration of picture quality during panning and generation of noise.
In order to ensure trouble-free camera operation, make sure that the cleaning function (page 38) is turned on.
• If cleaning the slip ring does not eliminate poor picture quality and noise, it could mean that the slip ring has
reached the end of its service life. Contact a qualified service person or system installer to have it replaced.
-10-
Attachment Pipe
Upper Base
Alarm Input Connector
Alarm Output Connector
Video Output Connector
Data Port
Rear sun shield (provided)
Front sun shield (provided)
Sun shield (pre-attached at factory)
Dome cover (do not remove)
Lens The lens cannot replaced.
Camera Safety Wire
Power Connector
for WV-CW960
Power Connector
for WV-CW964
W
A
RN
I
NG
I
NPOR
T
ANT
