Panasonic WV-SFN310 - Page 23

23
Finish: Main body:
Aluminum die cast
(Light gray)
Dome cover:
Clear polycarbonate resin
SF R 311
SF R 310
Main body:
Aluminum die cast (Sail white)
Dome cover:
Clear polycarbonate resin
SF N311
SF N310
Main body:
ABS resin (Sail white)
Dome cover:
Clear acrylic resin
*1 This is the power consumed when functions other than SD recording, the heater (for
WV-SFV311/WV-SFV310 only) and taking pictures are not operated.
*2 When using this product without turning the power off. (However, the temperature inside the
camera shall be –10 °C {14 °F} or higher.) Perform settings or startup operations when the
ambient temperature is –30 °C {–22 °F} or higher. The auto focus function is not available until
the heater unit of the camera raises the internal temperature of the camera.
*3 Only when installation work is properly performed according to the instructions in this book and
appropriate waterproof treatment is performed.
•
Camera
Image sensor: Approx. 1/3 type MOS image sensor
Built-in primary color filter
Effective pixels: 1296 (H) x 1032 (V) Approx. 1.3 mega pixels
Scanning area: 4.864 mm (H) x 3.891 mm (V) {3/16 inches (H) x 5/32 inches (V)}
Scanning system: Progressive
Minimum illumination:
SF V 311 SF R 311
SF N311
Color : 0.01 lx {0.00093 foot-candle}
(F1.6, Maximum shutter: Off (1/30 s), AGC: High)
0.0007 lx {0.00007 foot-candle}
(F1.6, Maximum shutter: max. 16/30 s, AGC: High)*
BW : 0.003 lx {0.00028 foot-candle}
(F1.6, Maximum shutter: Off (1/30 s), AGC: High)
0.0002 lx {0.00002 foot-candle}
(F1.6, Maximum shutter: max. 16/30 s, AGC: High)*
* Converted value
SF V 310
SF R 310
SF N310
Color : 0.01 lx {0.00093 foot-candle}
(F1.6, Maximum shutter: Off (1/30 s), AGC: High)
0.0007 lx {0.00007 foot-candle}
(F1.6, Maximum shutter: max. 16/30 s, AGC: High)*
BW : 0.008 lx {0.00074 foot-candle}
(F1.6, Maximum shutter: Off (1/30 s), AGC: High)
0.0005 lx {0.00005 foot-candle}
(F1.6, Maximum shutter: max. 16/30 s, AGC: High)*
Super-Dynamic: On (High)/ On (Normal)/ Off
* Super Dynamic function is automatically set Off on 60 fps mode.
Dynamic range: 133 dB typ. (Super Dynamic: On)
* When 60 frames is set, the function of super dynamic will change
to off.
