Panasonic WV-SPW531AL

17
Check before installation
Compatibilityofdevicesisrestricted.Before
installation,checktheratingsanddimensions
ofthedevicestobeused.
Contactyourdealerfordetails.
Before installation
Directlysecurethecameramountbracketoruse
WV-Q120A(adapterbox:
SPW531L

SPW311L
).
 • Anchorboltsandscrewsusedtomount
thecameraontheceilingorwallarenot
supplied.Prepareboltsandscrewsthat
matchthestructureandmaterialsofthe
installationlocationandsatisfytheperfor-
manceandreliabilityspecificationsshown
below.
SPW531L

SPW311L
Requiredscrews:M5(4pcs.)
Minimumpull-outstrength:724N{163lbf}
(per1pc.)
*PleasepreparefourM4screwsifyouare
installingitinametalswitchbox.
SPW532L

SPW312L
Requiredscrews:M4(3pcs.)
Minimumpull-outstrength:724N{163lbf}
(per1pc.)
Screw tightening
 • Thescrewsandboltsmustbetightened
withanappropriatetighteningtorque
accordingtothematerialandstrengthof
theinstallationarea.
 • Donotuseanimpactdriver.Useofan
impactdrivermaydamagethescrewsor
causetighteningexcessively.
 • Whenascrewistightened,makethe
screwatarightangletothesurface.After
tighteningthescrewsorbolts,perform
checkstoensurethatthetighteningis
sufficientenoughsothatthereisno
movementorlooseness.
Do not remove or loosen the screws on
the bottom of this product.
Ifthescrews(3pcs.)areloosened,thecamera
mayfall,resultinginaccidents.
*Thepictureaboveistheexample
ofWV-SPW531AL/WV-SPW311AL.
WV-SPW532L/WV-SPW312Lalsouse
thescrewsatthesamelocationsonthepicture.
Take notice of humidity
Installthisproductwhenthehumidityislow.If
installationisperformedwhenitisrainingorin
veryhumidconditions,theinsidemaybe
affectedbyhumidity,causingmist-overinside
thefrontcover.
