IMPORTANT! DO NOT DISCARD THE SHIP KIT LOCATED ON TOP OF THE DECK AND BELT. ALL NECESSARY
COMPONENTS NEEDED TO COMPLETE THE INSTALLATION ARE LOCATED IN THE SHIP KIT.
Section 6
7
Only one tool is required to assemble the
treadmill.
This tool is provided along with the bolt pack.
Keep the tool to tension the running belt in the
future.
1. ASSEMBLE THE UPRIGHT POSTS
Connect the cable(A) with (B) before you
assemble the upright posts to the base frame
Secure upright posts(2)&(3) with two short
screws(4) 、 four long screws(6) and six
washers(5and7).
2. ASSEMBLE THE CONSOLE
Secure the console base (1) to the upright
posts(2)&(3) with six washers (5and7) and six
screws(4)
Be careful not to pinch or damage the cable.
Assemble the console(1) and two hands by
four screws(E). Connect the cable(C) with (D),
To Next Page
