HS Consumer Treadmill
How To…Replace The Incline Motor - Continued
Tools Required: Phillips screwdriver, Sharp nose pliers, and open end wrench set. (All fasteners are metric. Make sure
that you have metric tools.)
Section 3
13
REMOVAL AND INSTALLATION
9. Replace the new incline motor.
a. Secure the long screw, fix up the incline
motor, not to secure tightly.
b. Incline the incline motor, secure the flat
washer& nut, not to secure tightly.
c. Secure the corresponding screws both
side together, till the screws tightly.
10. Connect all cables to the right orientation.
Please pay attention to the location of
cables. (Order of cables: white, red, black.
Please refer to the right photo)
11. Recommended that clear up the cables.
(You will need two
nylon cable ties.
Spec : 20cm long.
Please refer to the right photo)
12.
Proceed to the following page for
calibration the incline motor.
