HS Consumer Treadmill
EXPLODED DRAWING T561(110V)
Section 5
25
T561 (110V) Update: 2007.08.08
ITEM No. PARTS DESCRIPTION QTY.
1
Coating, frame, base
1
2
Cap, end, frame, base
2
3
Foot, front, frame, base
2
4
Coating, support, L
1
5
Coating, support, R
1
6
Stop, lock
1
7
Wheel, incline
2
8
Washer, star
6
9
Nut, nylon
10
10
Wheel, moving
1
11
Wheel, moving
1
12
Washer, roller
4
13
Washer, flat
15
14
Coating, frame, main
1
15
Cushion, deck
4
16
Shaft, release
1
17
Cap, pin, lock
1
18
Assy, pin, lock
1
19
Cap, pin, lock
1
20
Screw, dome
4
21
Coating, bracket, switch
1
22
Slider, track
2
23
Shaft, wheel, incline
2
24
Coating, frame, incline
1
25
Washer, frame, support
6
26
Motor(YC)
1
27
Sensor, speed, w/ cable
1
28
Assy, motor, incline, 110V
1
29
PCB, controller,110V
1
30
Assy, switch, 110V
1
31
Plating, bracket, motor
1
32
Screw, bottom-cut
2
33
Belt, drive
1
Explode drawing & part list 070808
