Digiplex DGP-848 - 15 - Programming Guide
First Digit
Second
Digit
Feature Select Programming
12345678
4 = Status 4
0Chime
Partition 1
Chime
Partition 2
Chime
Partition 3
Chime
Partition 4
Siren
Partition 1
Siren
Partition 2
Siren
Partition 3
Siren
Partition 4
1N/AN/AN/AN/ASmoke
Reset
Ground
Start
Kissoff N/A
2System
Trouble
Dialer
Trouble
Module
Trouble
Combus
Trouble
N/A N/A N/A Timer Loss
3 AC Fail Battery fail Aux. Limit Bell Limit No Bell ROM Error N/A N/A
4 TLM Fail to
Com1
Fail to
Com2
Fail to
Com3
Fail to
Com4
Fail to
Com PC
N/A N/A
5 Module
Tamper
Module
ROM Error
Module
TLM
Module Fail
to Com
Phone#
Printer Fault Module AC
Fail
Module
Battery Fail
Module Aux.
fail
6 Missing
Keypad
Missing Any
Module
N/A N/A N/A
Global Com-
bus Failure
Combus
Overload
Module Com-
bus Com Fail
7 = At the
Selected Time
0 00:00 00:15 00:30 00:45 01:00 01:15 01:30 01:45
1 02:00 02:15 02:30 02:45 03:00 03:15 03:30 03:45
2 04:00 04:15 04:30 04:45 05:00 05:15 05:30 05:45
3 06:00 06:15 06:30 06:45 07:00 07:15 07:30 07:45
4 08:00 08:15 08:30 08:45 09:00 09:15 09:30 09:45
5 10:00 10:15 10:30 10:45 11:00 11:15 11:30 11:45
6 12:00 12:15 12:30 12:45 13:00 13:15 13:30 13:45
7 14:00 14:15 14:30 14:45 15:00 15:15 15:30 15:45
8 16:00 16:15 16:30 16:45 17:00 17:15 17:30 17:45
9 18:00 18:15 18:30 18:45 19:00 19:15 19:30 19:45
A 20:00 20:15 20:30 20:45 21:00 21:15 21:30 21:45
B 22:00 22:15 22:30 22:45 23:00 23:15 23:30 23:45
8 = Utility Keys†
0 Utility Key 1 Utility Key 2 Utility Key 3 Utility Key 4 Utility Key 5 Utility Key 6 Utility Key 7 Utility Key 8
1 Utility Key 9 Utility Key 10 Utility Key 11 Utility Key 12 Utility Key 13 Utility Key 14 Utility Key 15 Utility Key 16
9 = Access
Granted
0 Door 01 Door 02 Door 03 Door 04 Door 05 Door 06 Door 07 Door 08
1 Door 09 Door 10 Door 11 Door 12 Door 13 Door 14 Door 15 Door 16
2 Door 17 Door 18 Door 19 Door 20 Door 21 Door 22 Door 23 Door 24
3 Door 25 Door 26 Door 27 Door 28 Door 29 Door 30 Door 31 Door 32
9 = User Code
Entered
8 Code # 01 Code # 02 Code # 03 Code # 04 Code # 05 Code # 06 Code # 07 Code # 08
9 Code # 09 Code # 10 Code # 11 Code # 12 Code # 13 Code # 14 Code # 15 Code # 16
A Code # 17 Code # 18 Code # 19 Code # 20 Code # 21 Code # 22 Code # 23 Code # 24
B Code # 25 Code # 26 Code # 27 Code # 28 Code # 29 Code # 30 Code # 31 Code # 32
C Code # 33 Code # 34 Code # 35 Code # 36 Code # 37 Code # 38 Code # 39 Code # 40
D Code # 41 Code # 42 Code # 43 Code # 44 Code # 45 Code # 46 Code # 47 Code # 48
E Code # 49 Code # 50 Code # 51 Code # 52 Code # 53 Code # 54 Code # 55 Code # 56
F Code # 57 Code # 58 Code # 59 Code # 60 Code # 61 Code # 62 Code # 63 Code # 64
A = Arming
0 Code # 01 Code # 02 Code # 03 Code # 04 Code # 05 Code # 06 Code # 07 Code # 08
1 Code # 09 Code # 10 Code # 11 Code # 12 Code # 13 Code # 14 Code # 15 Code # 16
2 Code # 17 Code # 18 Code # 19 Code # 20 Code # 21 Code # 22 Code # 23 Code # 24
3 Code # 25 Code # 26 Code # 27 Code # 28 Code # 29 Code # 30 Code # 31 Code # 32
4 Code # 33 Code # 34 Code # 35 Code # 36 Code # 37 Code # 38 Code # 39 Code # 40
5 Code # 41 Code # 42 Code # 43 Code # 44 Code # 45 Code # 46 Code # 47 Code # 48
6 Code # 49 Code # 50 Code # 51 Code # 52 Code # 53 Code # 54 Code # 55 Code # 56
7 Code # 57 Code # 58 Code # 59 Code # 60 Code # 61 Code # 62 Code # 63 Code # 64
A = Disarming
8 Code # 01 Code # 02 Code # 03 Code # 04 Code # 05 Code # 06 Code # 07 Code # 08
9 Code # 09 Code # 10 Code # 11 Code # 12 Code # 13 Code # 14 Code # 15 Code # 16
A Code # 17 Code # 18 Code # 19 Code # 20 Code # 21 Code # 22 Code # 23 Code # 24
B Code # 25 Code # 26 Code # 27 Code # 28 Code # 29 Code # 30 Code # 31 Code # 32
C Code # 33 Code # 34 Code # 35 Code # 36 Code # 37 Code # 38 Code # 39 Code # 40
D Code # 41 Code # 42 Code # 43 Code # 44 Code # 45 Code # 46 Code # 47 Code # 48
E Code # 49 Code # 50 Code # 51 Code # 52 Code # 53 Code # 54 Code # 55 Code # 56
F Code # 57 Code # 58 Code # 59 Code # 60 Code # 61 Code # 62 Code # 63 Code # 64
† See Utility Key Event Generation Table on page 17.
