Paradox Digiplex DGP-848 User Manual

Digiplex DGP-848 - 16 - Programming Guide
First Digit
Second
Digit
Feature Select Programming
12345678
B = Zone is OK
0 Zone # 01 Zone # 02 Zone # 03 Zone # 04 Zone # 05 Zone # 06 Zone # 07 Zone # 08
1 Zone # 09 Zone # 10 Zone # 11 Zone # 12 Zone # 13 Zone # 14 Zone # 15 Zone # 16
2 Zone # 17 Zone # 18 Zone # 19 Zone # 20 Zone # 21 Zone # 22 Zone # 23 Zone # 24
3 Zone # 25 Zone # 26 Zone # 27 Zone # 28 Zone # 29 Zone # 30 Zone # 31 Zone # 32
4 Zone # 33 Zone # 34 Zone # 35 Zone # 36 Zone # 37 Zone # 38 Zone # 39 Zone # 40
5 Zone # 41 Zone # 42 Zone # 43 Zone # 44 Zone # 45 Zone # 46 Zone # 47 Zone # 48
B = Zone is Open
8 Zone # 01 Zone # 02 Zone # 03 Zone # 04 Zone # 05 Zone # 06 Zone # 07 Zone # 08
9 Zone # 09 Zone # 10 Zone # 11 Zone # 12 Zone # 13 Zone # 14 Zone # 15 Zone # 16
A Zone # 17 Zone # 18 Zone # 19 Zone # 20 Zone # 21 Zone # 22 Zone # 23 Zone # 24
B Zone # 25 Zone # 26 Zone # 27 Zone # 28 Zone # 29 Zone # 30 Zone # 31 Zone # 32
C Zone # 33 Zone # 34 Zone # 35 Zone # 36 Zone # 37 Zone # 38 Zone # 39 Zone # 40
D Zone # 41 Zone # 42 Zone # 43 Zone # 44 Zone # 45 Zone # 46 Zone # 47 Zone # 48
C = Auto Zone
Shutdown
0 Zone # 01 Zone # 02 Zone # 03 Zone # 04 Zone # 05 Zone # 06 Zone # 07 Zone # 08
1 Zone # 09 Zone # 10 Zone # 11 Zone # 12 Zone # 13 Zone # 14 Zone # 15 Zone # 16
2 Zone # 17 Zone # 18 Zone # 19 Zone # 20 Zone # 21 Zone # 22 Zone # 23 Zone # 24
3 Zone # 25 Zone # 26 Zone # 27 Zone # 28 Zone # 29 Zone # 30 Zone # 31 Zone # 32
4 Zone # 33 Zone # 34 Zone # 35 Zone # 36 Zone # 37 Zone # 38 Zone # 39 Zone # 40
5 Zone # 41 Zone # 42 Zone # 43 Zone # 44 Zone # 45 Zone # 46 Zone # 47 Zone # 48
C = Zone Bypass
(when system
is armed)
8 Zone # 01 Zone # 02 Zone # 03 Zone # 04 Zone # 05 Zone # 06 Zone # 07 Zone # 08
9 Zone # 09 Zone # 10 Zone # 11 Zone # 12 Zone # 13 Zone # 14 Zone # 15 Zone # 16
A Zone # 17 Zone # 18 Zone # 19 Zone # 20 Zone # 21 Zone # 22 Zone # 23 Zone # 24
B Zone # 25 Zone # 26 Zone # 27 Zone # 28 Zone # 29 Zone # 30 Zone # 31 Zone # 32
C Zone # 33 Zone # 34 Zone # 35 Zone # 36 Zone # 37 Zone # 38 Zone # 39 Zone # 40
D Zone # 41 Zone # 42 Zone # 43 Zone # 44 Zone # 45 Zone # 46 Zone # 47 Zone # 48
D = Zone Fault
(Tamper / Fire
Loop)
0 Zone # 01 Zone # 02 Zone # 03 Zone # 04 Zone # 05 Zone # 06 Zone # 07 Zone # 08
1 Zone # 09 Zone # 10 Zone # 11 Zone # 12 Zone # 13 Zone # 14 Zone # 15 Zone # 16
2 Zone # 17 Zone # 18 Zone # 19 Zone # 20 Zone # 21 Zone # 22 Zone # 23 Zone # 24
3 Zone # 25 Zone # 26 Zone # 27 Zone # 28 Zone # 29 Zone # 30 Zone # 31 Zone # 32
4 Zone # 33 Zone # 34 Zone # 35 Zone # 36 Zone # 37 Zone # 38 Zone # 39 Zone # 40
5 Zone # 41 Zone # 42 Zone # 43 Zone # 44 Zone # 45 Zone # 46 Zone # 47 Zone # 48
D = RF Zone Fault
(Low battery
Supervision)
8 Zone # 01 Zone # 02 Zone # 03 Zone # 04 Zone # 05 Zone # 06 Zone # 07 Zone # 08
9 Zone # 09 Zone # 10 Zone # 11 Zone # 12 Zone # 13 Zone # 14 Zone # 15 Zone # 16
A Zone # 17 Zone # 18 Zone # 19 Zone # 20 Zone # 21 Zone # 22 Zone # 23 Zone # 24
B Zone # 25 Zone # 26 Zone # 27 Zone # 28 Zone # 29 Zone # 30 Zone # 31 Zone # 32
C Zone # 33 Zone # 34 Zone # 35 Zone # 36 Zone # 37 Zone # 38 Zone # 39 Zone # 40
D Zone # 41 Zone # 42 Zone # 43 Zone # 44 Zone # 45 Zone # 46 Zone # 47 Zone # 48
E = Fire /Burglar
Alarms
0 Zone # 01 Zone # 02 Zone # 03 Zone # 04 Zone # 05 Zone # 06 Zone # 07 Zone # 08
1 Zone # 09 Zone # 10 Zone # 11 Zone # 12 Zone # 13 Zone # 14 Zone # 15 Zone # 16
2 Zone # 17 Zone # 18 Zone # 19 Zone # 20 Zone # 21 Zone # 22 Zone # 23 Zone # 24
3 Zone # 25 Zone # 26 Zone # 27 Zone # 28 Zone # 29 Zone # 30 Zone # 31 Zone # 32
4 Zone # 33 Zone # 34 Zone # 35 Zone # 36 Zone # 37 Zone # 38 Zone # 39 Zone # 40
5 Zone # 41 Zone # 42 Zone # 43 Zone # 44 Zone # 45 Zone # 46 Zone # 47 Zone # 48
E = Fire/Burglar
Restore
8 Zone # 01 Zone # 02 Zone # 03 Zone # 04 Zone # 05 Zone # 06 Zone # 07 Zone # 08
9 Zone # 09 Zone # 10 Zone # 11 Zone # 12 Zone # 13 Zone # 14 Zone # 15 Zone # 16
A Zone # 17 Zone # 18 Zone # 19 Zone # 20 Zone # 21 Zone # 22 Zone # 23 Zone # 24
B Zone # 25 Zone # 26 Zone # 27 Zone # 28 Zone # 29 Zone # 30 Zone # 31 Zone # 32
C Zone # 33 Zone # 34 Zone # 35 Zone # 36 Zone # 37 Zone # 38 Zone # 39 Zone # 40
D Zone # 41 Zone # 42 Zone # 43 Zone # 44 Zone # 45 Zone # 46 Zone # 47 Zone # 48
F = Module
Troubles
0 Combus
Fault
Tamper ROM Error TLM Fail to
Comm.
Printer Fault AC Fail Battery Fail
1 Auxiliary
Output Fail
N/A N/A N/A N/A N/A N/A N/A
8 Combus
Fault
Restore
Tamper
Restore
ROM Error
Restore
TLM
Restore
Fail to
Comm.
Restore
Printer Fault
Restore
AC Fail
Restore
Battery Fail
Restore
9 Auxiliary Fail N/A N/A N/A N/A N/A N/A N/A
