DGP2-640 Icon LCD Keypad 1
1.0 Introduction
Thank you for choosing Paradox Security Systems. Our advanced
technology security systems provide you with reliable security
protection and powerful features which are easy to use. The
DGP2-640 Icon LCD keypad provides easy access to the security
system’s functions and status at a glance.
1.1 Specifications
Power input: 12-16 Vdc, 80mA maximum
PGM current limit: 50mA
Number of inputs: 1
Number of zones: 1 standard zone, no tamper recognition
Locate deactivation: Anti-tamper switch
Compatibility: Any Digiplex control panel
Table 1: LED Functionalities
LED Function Display Status
AC Light ON
OFF
Power On
Power Off
Status Light Green ON All zones closed
Green OFF Zone(s) open
Green flash Exit delay
Red ON Area(s) armed
Red OFF Area(s) disarmed
Red flash System in alarm
Green and yellow
flash simultaneously
Locate indication
Red and yellow
flash alternately
Combus fault
