Digiplex/DigiplexNE LCD Keypad 21n
6.0 Message Programming
SECTIONS [101] TO [148], [200] TO [204], and [301] TO [396]
Each section contains one message with a maximum of 16
characters. For more details and to record any changes, use the
Digiplex/DigiplexNE Modules’ Programming Guide.
The DigiplexNE control panel has up to 8 partitions, 96
zones and up to 999 user codes. The LCD keypad only
allows you to program the messages for up to 4
partitions, 48 zones and 96 user codes. The rest of the
messages can be programmed directly into the
Digiplex NE control panel. Refer to the DigiplexNE
Reference & Installation Manual and to the DigiplexNE
Programming Guide for more details.
After entering the section corresponding to the desired message,
use the Message Programming Keys (refer to Table 6.1 on
page 22) and the Special Function Keys on page 22 to change
the message to suit your installation needs. For example, section
[101] “ZONE 01” can be changed to “FRONT DOOR”.
Section [101] to [148] = “Zone 01” to “Zone 48” respectively
Section [200] = “Paradox Family”
Section [201] to [204] = “First Area”, “Second Area”, “Third
Area”, and “Fourth Area” respectively
Section [301] to [396] = “Code 01” to “Code 96” respectively
