Paradox K07C User Manual

Installation PAGE 11
4. You may insert the optional screw “C” under the Grafica keypad
through the space in the metal wall plate’s left tab (see Figure 7 on
page 10).
Removing Grafica
1. If required, remove the optional screw (see Figure 7 on page 10).
2. Gently slide the unit upwards with your hands until it separates from
the metal wall plate (see Figure 9).
Figure 9
Figure 10
A
A
- Metal wall plate
Grafica
(partial view)
Used with EVO/DGP panels only
(307USB and Memory Key connections)
