Introduction to the BASIC Stamps
Page 10 • BASIC Stamp Programming Manual 2.0b • www.parallaxinc.com
BASIC Stamp 2
The BASIC Stamp 2 is available in the above two physical packages. The
BS2-IC (Figure 1.4) uses surface mount components to fit in a small 24-pin
DIP package. The OEMBS2 (Figure 1.5) features an easier-to-trace layout
meant to aid customers who wish to integrate the BASIC Stamp 2 circuit
directly into their design (as a lower-cost solution). The OEMBS2 is
available in either an assembled form or a kit form. Both packages are
functionally equivalent.
SOUT
SIN
ATN
VSS
P0
P1
P2
P3
P4
P5
P6
P7
VIN
VSS
RES
VDD
P15
P14
P13
P12
P11
P10
P9
P8
24
23
22
21
20
19
18
17
16
15
14
13
1
2
3
4
5
6
7
8
9
10
11
12
BS2-IC
1.2“ (31 mm)
.62“ (16 mm)
.1“ (2.54 mm)
Figure 1.4: BASIC Stamp 2
(Rev. E) (BS2
-IC)
Figure 1.5: OEM BASIC Stamp 2
(Rev. A) (27290 or 27291)
Vin Vss Vdd RES P0 P1 P2 P3 P4 P5 P6 P7
OEM BASIC Stamp 2
(c) 1999 Rev A
RN1
Q3
+
XTAL
P8 P9 P10 P11 P12 P13 P14 P15
Q1
U3
Q2
RN2
C3
C2
TM
2.0“ (51 mm)
0.25“ (6 mm)
0.25“ (6 mm)
2.0“ (51 mm)
0.1“ (2.54 mm)
