5: BASIC Stamp Command Reference I2CIN
BASIC Stamp Programming Manual 2.0c www.parallaxinc.com Page 137
I2CIN
BS1 BS2 BS2e BS2sx BS2p
I2CIN Pin, SlaveID, Address {\LowAddress}, [InputData]
Function
Receive data from a device using the I
2
C protocol.
Pin is a variable/constant/expression (0 or 8) that specifies which
I/O pins to use. I
2
C devices require two I/O pins to communicate.
The Pin argument serves a double purpose; specifying the first pin
(for connection to the chip's SDA pin) and, indirectly, the other
required pin (for connection to the chip's SCL pin). See explanation
below. Both I/O pins will be toggled between output and input
mode during the I2CIN command and both will be set to input
mode by the end of the I2CIN command.
SlaveID is a variable/constant/expression (0 255) indicating the
unique ID of the I
2
C chip.
Address is a variable/constant/expression (0 255) indicating the
desired address within the I
2
C chip to receive data from. The
Address argument may be used with the optional LowAddress
argument to indicate a word-sized address value.
LowAddress is a variable/constant/expression (0 255) indicating
the low-byte of the word-sized address within the I
2
C chip to receive
data from. This argument must be used along with the Address
argument.
InputData is a list of variables and modifiers that tells I2CIN what to
do with incoming data. I2CIN can store data in a variable or array,
interpret numeric text (decimal, binary, or hex) and store the
corresponding value in a variable, wait for a fixed or variable
sequence of bytes, or ignore a specified number of bytes. These
actions can be combined in any order in the InputData list.
Quick Facts
BS2p
Values for Pin
0 or 8
I/O pin
arrangement
When Pin is 0: When Pin is 8:
0: Serial Data (SDA) pin 8: Serial Data (SDA) pin
1: Serial Clock (SCL) pin 9: Serial Clock (SCL) pin
Transmission
Rate
Approximately 81 kbits/sec (not including overhead).
Special notes
Both the SDA and SCL pins must have 4.7 K pull-up resisters.
The I2CIN command does not allow for multiple masters.
The BASIC Stamp cannot operate as an I
2
C slave device.
Table 5.16: I2CIN Quick Facts.
p
