Customer Guide
HPAC Cell Cleaning
©2015 Parata Systems, LLC page 31 of 40 Parata Technical Assistance Center
120-0465 Rev 03 1-888-PARATA1 (727-2821)
7.4.b Position the tape with the sticky side toward the nozzle and insert one
end of the tape (approximately half of the length) into the gap
between the nozzle and the body of the cell. Then press the remaining
tape down onto the side of the nozzle cover.
Step 7.4.b
7.4.c Use a flat object, such as a counting spatula, to press the tape against
the back of the nozzle.
Step 7.4.c
7.4.d Repeat steps 7.4.a through 7.4.c to apply tape to the other side of the
nozzle cover.
7.5 Obtain a foam plug from the cleaning kit and install it.
7.5.a Turn the white width knob on the side of the cell clockwise to adjust
the setting to A.25.
