JOG REN Details
The JOG REN command (Transfer Current Position into Jog Offset)
clears the Coordinated Moves Profiler of a given axis and adds the
difference to the Jog Profiler offset (example: JOG REN X). It can
also be used to preload a position into the Coordinated Moves
Profiler (adjusting the Jog Profiler to make up the difference)
(example: JOG REN X2). In either case, the Gear and Cam profilers
and the Primary and Secondary setpoints do not change.
The drawing in Figure 11 illustrates JOG REN as it clears the
Coordinated Moves Profiler.
Figure 11 JOG REN Clears Coordinated Moves Profiler (JOG REN X)
Making Motion 73
