Parker DB Series User Manual

44
DB Series Nitrogen Generator DB5-20 Model
PROPERTY OF PARKER-HANNIFIN CORPORATION
THIS DOCUMENT CONTAINS INFORMATION THAT IS CONFIDENTIAL AND PROPRIETARY TO PARKER HANNIFIN, AND IS FURNISHED ON THE UN DERSTANDING THAT THE DOCUMENT AND THE INFORMATION IT CONTAINS WILL NOT BE COPIED OR DISCLOSED TO OTHERS OR USED FOR ANY PURPOSE OTHER THAN CONDUCTING BUS INESS WITH PARKER, AND
COPYRIGHT IS THE FIRST YEAR INDICATED ON THIS DOCUMENT. ALL RIGHTS RESERVED.
WILL BE RETURNED AND ALL FURTHER U SE DISCONTINUED UPON REQUEST BY PARKER.
DRAWN BY DATE SCALE UNITS
TITLE SIZE
SHEET
DRAWING NUMBER
REVISION
PART NUMBER
MATERIAL
PARKER HANNIFIN LANCASTER, NY 14086 USA
INCHES
OF
C
JK
1:12
DUAL BED NITROGEN GENERATOR
DB-AB
-
2 2
DB-AB
1/28/2022
ALL TOLERA NCES: ± 1/64
ANGLES: ± 2º
FRACTIONS: ± 1 /4
ANGLES: ± 3º
SHEET METAL PARTS
WELDED PARTS AND
SALES DRAWINGS
USE CORRESPONDING TOLERANCES UNLESS OTHERWISE SPECIFIED
ANGLES ± 1/2
~
2 PLACE (.00): ±.01
MACHINED PARTS
3 PLACE (.000): ±.005
R
a
SURFACE FINISH
125
NITROGEN GENERATOR
MODEL AIR IN TO NST FROM NST N2 OUT
WEIGHT (LBS) WEIGHT (KG)
DB-5 1/2" NPT 1/2" NPT 1/2" NPT 1/2" NPT 905 410
DB-10
1/2" NPT 1/2" NPT 1/2" NPT 1/2" NPT
1105 501
NITROGEN SURGE TANK
NST IN NST OUT
WEIGHT (LBS) WEIGHT (KG)
1/2" NPT 1/2" NPT 160 73
DB-AB
