PROPERTY OF PARKER-HANNIFIN CORPORATION
THIS DOCUMENT CONTAINS INFORMATION THAT IS CONFIDENTIAL AND PROPRIETARY TO
PARKER HANNIFIN, AND IS FURNISHED ON THE UN DERSTANDING THAT THE DOCUMENT
AND THE INFORMATION IT CONTAINS WILL NOT BE COPIED OR DISCLOSED TO OTHERS
OR USED FOR ANY PURPOSE OTHER THAN CONDUCTING BUS INESS WITH PARKER, AND
COPYRIGHT IS THE FIRST YEAR INDICATED ON THIS DOCUMENT. ALL RIGHTS RESERVED.
WILL BE RETURNED AND ALL FURTHER U SE DISCONTINUED UPON REQUEST BY PARKER.
DRAWN BY DATE
SCALE UNITS
TITLE
SIZE
SHEET
DRAWING NUMBER
REVISION
PART NUMBER
MATERIAL
PARKER HANNIFIN
LANCASTER, NY
14086 USA
INCHES
OF
C
JK
1:14
DUAL BED NITROGEN GENERATOR - EXTENDED
CABINET
DBEC-AB
-
2 1
DBEC-AB
1/28/2022
ALL TOLERA NCES: ± 1/64
ANGLES: ± 2º
FRACTIONS: ± 1 /4
ANGLES: ± 3º
SHEET METAL PARTS
WELDED PARTS AND
SALES DRAWINGS
USE CORRESPONDING TOLERANCES UNLESS OTHERWISE SPECIFIED
ANGLES ± 1/2
~
2 PLACE (.00): ±.01
MACHINED PARTS
3 PLACE (.000): ±.005
R
a
SURFACE FINISH
125
JOB NUMBER: __________________________________________________________
REVIEWED BY: __________________________ DATE: _________________________
78 9/16 in
1995.272 mm
50 3/8 in
1280.147 mm
28 3/4 in
729.836 mm
47 15/16 in
1217.714 mm
40 7/16 in
1026.518 mm
14 1/8 in
359.457 mm
53 3/8 in
1355.023 mm
6 1/16 in
153.448 mm
4 1/2 in
114.302 mm
AIR IN
N2 OUT
FROM NST
TO NST
NST OUT
NST IN
NITROGEN
SURGE TANK
51 9/16 in
1309.395 mm
n
24 7/16 in
n
620.776 mm
Ø5/8 in
Ø17.272 mm
n
20 in
n
508.000 mm
36 1/16 in
916.407 mm
39 5/16 in
998.957 mm
NITROGEN
GENERATOR
