Parker ER Series

Parker Hannifin Corporation
Automation Actuator Division
Wadsworth, OH 44281
13
Automation
ER Series Rodless Actuator
PM-ER01/USA Maintenance Instructions and Parts List
PART DESCRIPTION QTY 32 50 80
1B CARRIAGE BODY, SQUARE RAIL 1 ER32R03SS ER50R03SS ER80R03SS
11 SWITCH MAGNETS 2 ER32M10 ER80M10 ER80M10
12 NUT RETAINER 1 ER32R07 ER50R07 ER80R07
13 NUT RETAINER SCREWS 4 CF-CM4X0.7-012 CF-CM4X0.7-012 CF-CM6X1.0-020
14 NUT RETAINER SET SCREWS 2 SB-CM4X0.7-006 SB-CM6X1.0-008 SB-CM81.25-010
15 ACME\BALL SCREWS NUT 1 TNXXXXX TNXXXXX TNXXXXX
16 U.H.M.W. COVER SLIDE 1 ER32R14BSC ER50R14BSC ER80R14BSC
17B TOP LOAD PLATE (SCREW) 1 ER32R05-S ER50R05-S ER80R05-S
18 TOP LOAD PLATE SCREWS 8 CS-CM3X0.5-010-Z CS-CM4X0.7-012-Z CS-CM5X0.8-016-Z
19 STRIP GUIDES 2 ER32R06 ER50R06 ER80R06
20 STRIP GUIDES SCREWS 4 CS-CM3X0.5-008-Z CS-CM4X0.7-008-Z CS-CM4X0.7-010-Z
22 SQUARE RAIL BEARING SETS 1 RA377-XXXX RA378-XXXX RA379-XXXX
23 SQUARE RAIL BEARING SCREWS 8 CS-CM3X0.5-020 CS-CM3X0.5-008 CS-CM5X0.8-035
24 SERRATED WASHER 8 B2124 B2125 B2125
28 END CAP SNAP RINGS 2 BNVH-112 BNVH-162 BNVH-275
29 CARRIAGE STOPS 2 ER32M02 ER50M02 ER80M02
30 SCREW DRIVE END CAP BUMPERS 2 ET32M01 ET50M01 ET80M01
31 THRUST BEARINGS 2 RA373 RA336 RA342
32 SCREW SHAFT SLEEV E 1 ER32R08 N/A N/A
33 SCREW DRIVE OPP.SIDE END CAP 1 ER32E01 ER50E01 ER80E01
34 STRIP GUIDE CLA MP 2 ER32M05 ER50M05 ER80M05
35 STRIP GUIDE CLAMP SCREWS 4 CB-CM4X0.7-008-Z CB-CM4X0.7-008-Z CB-CM4X0.7-008-Z
36 SCREW DRIVE MOTOR SIDE END CAP 1 ER32E02 ER50E02 ER80E02
37 BEARING LOCKNUT 1 ET32R07 B8777 B8776
37A BEARING LOCKNUT SCREW 1 CS-CM3X0.5-008 SUPPLIED SUPPLIED
38 SCREW DRIVE END SHCS IN LINE 4 CS-CM5X0.8-030 CS-CM6X1.0-035 CS-CM8X1.25-050
39A TIE ROD BOLTS 4 M6-M5-A M8-M6-A M10-M8-A
40 TIE ROD NUTS 4 32-27015 50-27015 80-27015
41 RADIAL BEARING 1 RA339 RA374 RA375
57 ACME/BALL SCREW 1 ERTSXXXXXNXXXXXX ERTSXXXXXNXXXXXX ERTSXXXXXNXXXXXX
58A ACME/BALL SCREW KEY IN LINE 1 B8534M2-06 B8534M2-08 B8534M5-14
58B ACME/BALL SCREW KEY PARALLEL 1 B8534M2-20 B8534M3-20 B8534M5-32
59 STRIP SEAL 1 ER32M06BSC ER50M06BSC ER80M06BSC
60 STRIP SEAL MAGNETS 2 ER32M11BSC ER32M11BSC ER32M11BSC
61 BODY 1 ER32CXXXX ER50CXXXX ER80CXXXX
62 SQUARE RAIL SCREWS - CS-CM3X0.5-006 CS-CM3X0.5-006 CS-CM4X0.7-016
63 SQUARE RAIL SCREW WASHERS - B2124 B2125 B2125
Parts List- Square Rail/Screw Drive
