Gemini GT6 Hardware Installation Guide
Power Specifications
Input Power
AC
Drive AC Input Range
GT6-L5 95VAC – 132VAC, 50/60 Hz, single phase
GT6-L8 95VAC – 132VAC, 50/60 Hz, single phase
GT6-U5 95VAC – 132VAC and 190VAC – 264VAC, 50/60 Hz, single phase
GT6-U8 95VAC – 132VAC and 190VAC – 264VAC, 50/60 Hz, single phase
Connector
Drive connector: #8 (M4) screw terminals.
Mating terminals: spade fork, 0.325” maximum width
CAUTION
Do not operate GT6-U5/8 in the 132VAC – 190VAC range, or the drive will be
permanently damaged.
CAUTION
You must connect V DBL to L2/N on GT6-U5/8 to enable the voltage doubler for
120VAC operations.
CAUTION
Do not operate GT6-L5/8 above 132VAC, or the drive will be
permanently damaged.
+24VDC “Keep Alive” Power
Input voltage range: 19.2 – 28.8 VDC
Input current: 500 mA (maximum)
Output Power
Output Current Output Voltage (motor bus)
Drive (amps, peak) (DC, rms)
GT6-U5 5.0 74
GT6-U8 7.5 74
GT6-L5 5.0 170
GT6-L8 8.0 170
Connector
Drive connector: #8 (M4) screw terminals.
Mating terminals: spade fork, 0.325” maximum width
