Parker Gemini GT6 Series

Appendix B – Non-Compumotor Motors 67
Terminal Connections
After you determine the motor’s wiring configuration, connect the motor leads to
the Gemini drive’s MOTOR connector according to the following figure.
4-Lead Motor 6-Lead Motor
8-Lead Motor
Series
8-Lead Motor
Parallel
A+
A-CT
A–
B–
B-CT
B+
Gemini
Terminals
A+
A–
B+
B–
Gemini
Terminals
A+
A–
B+
B–
Gemini
Terminals
A+
A–
B+
B–
Gemini
Terminals
A+
A–
B+
B–
A+
A–
B–
B+
A1
A2
A3
A4
B4
A-CT
B-CT
B1
B2
B3
A1
A2
A3
A4
B4
B1
B2
B3
Non-Compumotor Motor Connections
