Chapter 1 – Introduction
7
Gemini Product Names
The following table lists the meanings of letters and numbers in Gemini product
names. Notice that “T” is associated with step motor products (“sTep”), and “V” is
associated with servo motor products (“serVo”).
Control Level:
Step Motor Drives and Drive/Indexers Servo Motor Drives and Controller/Drives
GT Step Motor Drive GV Servo Motor Drive
GT6 6000-based Step Motor Indexer GV6 6000-based Servo Controller
GT6K 6K-based Step Motor Indexer GV6K 6K-based Servo Controller
Power Level:
Step Motor Power Levels Servo Motor Drives and Controller/Drives
L5 120VAC, 5A at 170VDC L3 120VAC, 3A at 170VDC
L8 120VAC, 8A at 170VDC U3 120/240VAC 1 Ø, 3A at 170/340VDC
U5 120/240VAC 1 Ø, 5A at 74VDC U6 120/240VAC 1 Ø, 6A at 170/340VDC
U8 120/240VAC 1 Ø, 8A at 74VDC U12 120/240VAC 1 Ø, 12A at 170/340VDC
H20 208/240VAC 3 Ø, 20A at 294/340VDC
(1 Ø, 16A at 294/340VDC)
Amperage values represent continuous current, peak of the sine wave.
“L” = “Low” voltage input (120VAC)
“U” = “Universal” voltage input (120/240VAC)
“H” = “High” voltage input (208/240VAC)
Options:
Data Bus (-db) Option (for GT6 and GV6 only):
IS Interbus
PB Profibus
SC SERCOS
Feedback (-fb) Option (for Servos only):
E Encoder/Hall
R Resolver
Ship Kit Options:
NK No Kit
Format:
Gemini
V or T
6, 6K or Blank
L, H or U
GT = 5, 8; GV = 3, 6, 12, 20
E, R, or Blank
IS, PB, SC or Blank
-NK or Blank
Drive:
Type:
Control:
Input Voltage Level:
Output Motor Current:
Feedback Option:
Data Bus:
Ship Kit Option:
GT6-L5 -SC-NK
Format Example
