Parker GT Series - Drive Mounting Guidelines

Appendix A – Specifications 59
6.00
(153.0)
5.40
(138.0)
Product
3.13 (79.4) 0.38 (9.5)GT-U5
3.75 (95.3) 1.00 (25.4)GT-U8
OW
Overall Width
inches (mm)
FH
Fin Height
inches (mm)
OW
2.75
(70)
1.38
(35)
FH
8.9
(226.1)
9.63
(244.5)
9.9
(251.5)
3x clearance
for #8 or M4
mounting screws
1.00
(25.4 )
0.88
(22.2)
Dimensions in inches (mm)
Drive Dimensions (Taller Enclosure)
