Tie Rod and Prole Pneumatic Cylinders
P1F Series
Catalog 0980
Dimensional Data
P1F-L, P1F-P [mm]
Bore
size A
ØB
d11
ØBA
d11 BG ØD D4 E EE G KK L3 L8 L12 PL PP RT
32
22 30 30 17 12 42.5 47 G1/8 28.4 M10x1.25 4.5 94
6 14 20 M6
40 24 35 35 17 16 48 53 G1/4 33 M12x1.25 4.5 105 6.5 16 22 M6
50 32 40 40 18 20 59.5 64.5 G1/4 33.4 M16x1.5 4.5 106 8 15.5 21.5 M8
63 32 45 45 18 20 69.5 75 G3/8 39.4 M16x1.5 4.5 121 8 18 28 M8
80 40 45 45 19.5 25 86 94 G3/8 39.4 M20x1.5 5.5 128 10 20 30 M10
100 40 55 55 19.5 25 103 111 G1/2 44.3 M20x1.5 5.5 138 10 18 33 M10
125 54 60 60 20 32 130 136 G1/2 50.8 M27x2 0 160 13 20 40 M12
Bore
size SS SW TG TT VA LE LG LK LL8 LPL LPP LSS LTT LVD LWH LX
32
5 10 32.5 6.5 3.6 50 71 18.5 137 53 63 3 4.5 4 15 6
40 6 13 38 9 3.5 57.4 76.5 20 149 56 67.5 3 3 4 16 6
50 6 17 46.5 9 3.6 70 80 21 153 65 71 8 5.5 4 17 7
63 10 17 56.5 11 3.5 82.4 96 30 178 76.5 87 8.5 3 4 17 7
80 11.5 22 72 14 3.5 100 110 35 199 89 101 9 6 4 20 7
100 11.5 22 89 14 3.5 116 132 54 226 112 122 12 6 4 20 7
125 0 27 110 22 5.5 139 144.5 65.5 254 124.5 134.5 14 6 6 27 7
P1F-P
Bore
size Ø
Air volume
base 0 mm
Air volume per
stroke of
[cm³] [cm³/100 mm]
32 40 80
40 68 126
50 91 196
63 137 312
80 289 503
100 417 785
125 809 1227
Tolerances [mm]
Bore size A L8 TG
Stroke tolerance
s ≤ 350 mm
350 mm < s
≤ 600 mm s > 600 mm
32 0/-0.5 ± 0.3 ±0.4 + 1.7 + 1.9 + 2.3
40 0/-0.5 ± 0.3 ±0.4 + 1.7 + 1.9 + 2.3
50 0/-0.5
- 0.3 / + 0.5 ±0.4 + 1.8 + 2 + 2.4
63 0/-0.5
- 0.6 / + 0.2 ±0.4 + 1.9 + 2.1 + 2.5
80 0/-0.5 ± 0.4 ±0.4 + 1.9 + 2.1 + 2.5
100 0/-0.5 ± 0.5 ±0.4 + 2.0 + 2.2 + 2.6
125 0/-1.0 ± 0.5 ±0.4 + 2.1 + 2.3 + 2.7
