| User’s Manual
Sentinel
™
10
4.1 Safety
The Sentinel is tted with uorocarbon seals. All process uid
must be compatible with uorocarbon. Contact Parker with uid
compatibility questions.
4.2 Preparing for Use
Check that the oil in the vacuum pump is at the proper level before
operating.
1. Place the Sentinel on a at surface
2. Lock the brake on the two front wheels
3. Connect the hoses:
a. Hydraulic Outlet
b. Hydraulic Inlet
c. Water Drain
4. Plug in the power cord
Ensure proper ventilation when operating.
See the technical specication for proper power requirements.
4 Operation
This chapter describes the operation of the Sentinel.
2
2
3a
3b
3c
4
