| User’s Manual
Sentinel
™
7.1 Safety Precautions
Switch off the Sentinel completely before disposing of the Sentinel.
Always check that the Sentinel is disconnected from its power sources before disposing of the Sentinel.
See Chapter 2 for more information and safety precautions.
7.2 Disposing of the Sentinel
When disposing of the Sentinel, always consult Parker Hannin.
Only qualified personnel is authorized to dispose of the Sentinel.
7.3 Environmental Aspects
Please observe the following environmental aspects:
• Dispose of the Sentinel according to the legal and local regulations.
• Re-use parts and substances of the Sentinel and process parts and substances in an environmentally-
friendly manner if re-use is impossible.
• Discharge harmful, dangerous and possibly contaminated substances (or liquids) according to the legal
and local regulations.
Make sure the Sentinel is disposed of in a safe way and according to the environmental rules in the
country of use.
7 Disposal
This chapter describes how to dispose of the Sentinel.
8 Parts List
Part Number Description
00424 Float Switch
06F20C2218A1FPH80 Condensate Drain Valve
20072409 IQAN MD3 display module
2820008 Pressure Sensor
3349116565 Gear Pump
40CN205QEVE2GS164 Filter
7221GBN51V00N0D300C2 Inlet valve
7221GBN51V00N0D300C2 Recirculation valve
936711Q Hydraulic Particulate Element
943236 Mounting Bracket Kit
943237 Service Kit (includes TriCep-
tor air breather, hydraulic
particulate element, coalesc-
ing element, vacuum pump
exhaust element, vacuum
pump oil)
943238 Cordset (pigtail end)
used with 943116 and
943213 only
Part Number Description
B-10235-0-230 Heater 230VAC
B-10235-0-380 Heater 380VAC
B-10235-0-460 Heater 460VAC
CEM3546T Hydraulic Pump Motor
MPS-V33N-PGAT Vacuum Sensor
MS1504 Moisture Sensor
For Service Requiring No Yellow Metals
Part Number Description
945302 No Yellow Metals Accessory
Kit - wetted components
only (includes below part
numbers)
15U29-00V Inlet Valve
12F22C6148A3FPH80 Recirculation Valve
12F-C12L-1/3-SS Check Valve
F800S Flow Control Valve
