| User’s Manual
Sentinel
™
4.6 Adjusting Set Points
The adjustable set points are:
• Moisture high limit
• Sample rate
• Moisture set point (low limit)
• Temperature
• Unit Selector
Use the arrow buttons to scroll through the options and press the
“OK” button when a selection has been made.
See Chapter 3 for the set points function
Press the escape key (back arrow) to return to the Set-Up Screen
1. Once the adjustable parameter is chosen, use the up and down
arrows to adjust to the desired setting, press ok to accept.
2. Press the escape key once to return to the point selection page.
4.7 Removing from Service
Make sure the Sentinel has stopped running before taking it out of
service.
1. Purge the vacuum pump from the set-up screen by pressing F3.
2. Make sure the oil is emptied from the system by pressing F1
“Run Empty” within the set-up screen.
3. Drain the condensate by pressing and holding F2 within the set-
up screen.
4. Turn off power via the main switch.
5. Disconnect the power cord from the back of the unit.
6. Disconnect all the hoses from the back of the unit.
Pressing the escape key while on the set-up screen, with the
Sentinel not running, will open the inlet valve to allow for the heater
tube to be drained.
Oil may leak from the hoses
