 Hold the heating button
6
pressed while you cut the hard foam to the required size using the glow
wire
3
.
 Release the heating button
6
at the end of each cut. The heating button
6
must not be pressed
continuously or fixed in the pressed position. FIRE HAZARD!
z Cutting options
Straight cut
Set the angle-adjustable guide rails
10
to 90° (see Fig. F) and set the angle adjustment
of the cutting bow
11
to 0°. Put the material in place and move to the required
position. If necessary, use the stop for length adjustment
27
as an aid. Press the
heating button
6
and keep it pressed. Push the cutting bow
2
in the direction of the
material until the material is completely cut. Release the heating button
6
.
The glow wire
3
will cool down in a few seconds.
Bevel cut
Set the angle-adjustable guide rails
10
to the required cutting angle (see Fig. F).
Set the angle adjustment of the cutting bow
11
to 0°. Put the material in place and
move to the required position. If necessary, use the stop for length adjustment
27
as
an aid. Press the heating button
6
and keep it pressed. Push the cutting bow
2
in the
direction of the material, until the material is completely cut. Release the heating
button
6
. The glow wire
3
will cool down in a few seconds.
Mitre cut
Set the angle-adjustable guide rails
10
to 90° (see Fig. F). Set the angle adjustment of
the cutting bow
11
to the required angle of the mitre cut. Put the material in place and
move to the required position. If necessary, use the stop for length adjustment
27
as an
aid. Press the heating button
6
and keep it pressed. Push the cutting bow
2
in the
direction of the material, until the material is completely cut. Release the heating button
6
.
The glow wire
3
will cool down in a few seconds.
Dovetail cut/step cut
Set the angle-adjustable guide rails
10
to 90° (see Fig. F) and set the angle adjustment
of the cutting bow
11
to 0°. Using the depth stop
28
: To do this undo the screw for the
depth stop
25
on both sides of the cutting rails. Move each depth stop
28
to the
required position and fix it in place by tightening the screw for the depth stop
25
(PLEASE NOTE: In order to prevent the cutting rails
2
from tilting, the depth stops
28
must be set at the same position on both sides of the cutting rails
2
). Put the material in place. Press the
heating button
6
and keep it pressed. Push the cutting rails
2
in the direction of the material, until the
cutting rails
2
are stopped by the depth stop
28
. The step depth which has been set will be cut.
When you have reached the step depth, pull the material away in the required direction, until the step is
completely cut. Release the heating button
6
. The glow wire
3
will cool down in a few seconds.
Groove cut
Set the angle-adjustable guide rails
10
to 90° (see Fig. F) and set the angle adjustment
of the cutting bow
11
to 0°. Using the depth stop
28
: To do this undo the screw for the
depth stop
25
on both sides of the cutting rails
2
. Move each depth stop
28
to the
