heat sealed. You will achieve perfect cutting results. Any use that differs to the intended use as stated
above is prohibited and potentially dangerous. Damage or injury caused by misuse or disregarding the
above warning is not covered by the warranty or any liability on the part of the manufacturer.
The device is not intended for commercial use. Commercial use will void the guarantee.
z Scope of delivery
1 Glow Wire Hard Foam Cutter
1 set of operating instructions
1 brass brush
1 tool to replace the glow wire
3 replacement glow wires
z Equipment
PLEASE NOTE: After unpacking the product, please check that all of the package contents are
present and that the glow wire hard foam cutter is in perfect condition. Do not use the device if it is
defective.
To do this see Fig. A-K:
1
Glow Wire Hard Foam Cutter
16
Screws
2
Cutting bow
17
Electrical connection
3
Glow wire
17a
Socket for electrical connection
4
Cutting board
18
Spring
5
Cutting board extension
19
Brass brush
6
Heating button
20
Tool to replace the glow wire
7
Side telescopic feet
21
Replacement glow wire
8
Mains plug
22
Screw for position adjustment
9
Transformer
23
Screws for angle adjustment of the cutting
bow
10
Adjustable guide rails
24
Screw for angle adjustment
Adjustable guide rails
11
Angle adjustment of the cutting bow
25
Screw for depth adjustment
12
Screw for telescopic foot
26
Locking pins
13
Snap screws for side telescopic feet
27
Stop for length adjustment
14
Guide rails
28
Depth stop
15
Rear telescopic foot
29
Railing fixing
15a
Fixing rails for rear telescopic foot
30
Allen key
PLEASE NOTE: The use of the term ‘product’ or ‘device’ in the following text refers to the glow
wire hard foam cutter named in these operating instructions.
