Any other use that is not expressly
permitted in this instruction manu-
al may pose a serious hazard to the
user and result in damage to the
device. The operator or user of the
machine is responsible for any acci-
dents or personal injury and/or ma-
terial damage to third parties or their
property. The machine is intended to
be used by do-it-yourselfers. It was
not designed for heavy commercial
use. The warranty is void in the case
of commercial use. The manufacturer
is not liable for damage caused by
improper use or incorrect operation.
Scope of delivery/
accessories
Unpack the device and check that
everything is present.
Dispose of the packaging material
properly.
• Pressure Washer
• Trigger gun
• Lance
• High-pressure hose
• Cleaning agent tank (pre-as-
sembled)
• Standard vario-nozzle
• Turbo dirt blaster
• Rotating washing brush
• Cleaning agent URM 500 (500 ml)
• Coupling (Water connection), Filter
insert
• Quick connector with garden hose
adaptor
• Nozzle cleaning needle
• Translation of the original instruc-
tions
Small parts/Accessories are stored
in a sealed paper bag.
Description of functions
The pressure washer cleans using a
high-pressure water jet.
If necessary, it can also be operated
with additional cleaning agents.
Please refer to the descriptions below
for information on how the operating
elements work.
Overview
The illustrations for the
device can be found on
the front fold-out page.
1 Lance
2 U-handle
3 Release (U-handle)
4 On/Off switch
5 Nozzle cleaning needle
6 Trigger gun
7 Holder (Turbo dirt blaster)
8 Pressure indicator
9 Holder (Trigger gun)
10 Rotating washing brush
11 High-pressure hose
12 Hose reel with crank handle
13 Holder (Accessories)
14 Holder (Power cord)
15 Power cord
16 Sealing cap with suction hose
17 Cleaning agent tank
18 Wheels
19 Coupling (Water connection)
20 Filter insert
21 Water connection
22 Standard vario-nozzle
23 Guide for high-pressure hose
24 Switch lever
25 Child safety lock
26 Release (High-pressure hose)
27 Articulated joint
28 Release button
