20
PARTS LIST
Fuses
Part No. Fuse Rating
139E6 Instrument Fuse Fast acting, 1 Amp, 250VAC
139E10 Cooling Fuse Fast acting, .25 Amp, 250VAC
2074E Line Fuse(s) Fast acting, 20 Amp, 250VAC
959E5 Motor Board
Fuse (A+)
Very Fast acting, 8 Amp,
250VAC
185E2 Motor Board
Fuse (L)
Fast acting, 10 Amp, 250VAC
Motor breaker / fuse
139E8 1/2 hp, 180VDC Slo-blo, 2.5 Amp, 250VAC
139E19 1/4 hp, 180VDC Slo-blo, 1.5 Amp, 250VAC
139E20 3/4 hp, 180VDC Slo-blo, 4.0 Amp, 250VAC
801E 1/12 hp, 90VDC Circuit breaker, 1.0 Amp
801E 1/17 hp, 90VDC Circuit breaker, 1.0 Amp
801E3 1/8 hp, 90VDC Circuit breaker, 1.5 Amp
801E2 1/4 hp, 90VDC Circuit breaker, 2.5 Amp
801E4 1/2 hp, 90VDC Circuit breaker, 5.0 Amp
CAUTION! For continued protection
against possible hazard, replace fuses
with same type and rating of fuse.
Cooling Solenoids
Part No. Description
A160HW3EB Solenoid Valve Pkg 115V
A160HW3EE Solenoid Valve Pkg 230V
A160HW7EB Solenoid Valve Pkg 115V 10FT
A160HW7EE Solenoid Valve Pkg 230V 10FT
A160HW8EB Solenoid Valve Pkg 115V 20FT
A160HW8EE Solenoid Valve Pkg 230V 20FT
A160HW9EB Solenoid Valve Pkg 115V 30FT
A160HW9EE Solenoid Valve Pkg 230V 30FT
Accessories
Temperature (Temperature Control Module)
Aux. Temp. (Auxiliary Temperature Module)
Part No. Description
A470E2 Thermocouple extension wire, 5-ft
A470E4 Thermocouple extension wire, 10-ft
A470E7 Thermocouple extension wire, 15-ft
A470E5 Thermocouple extension wire, 20-ft
A470E8 Thermocouple extension wire, 25-ft
A470E6 Thermocouple extension wire, 30-ft
A470E9 Thermocouple extension wire, 35-ft
A470E10 Thermocouple extension wire, 40-ft
A472E Thermocouple, type-J, 7-1/2" length
A472E2 Thermocouple, type-J, 9-1/2" length
A472E3 Thermocouple, type-J, 11-1/2" length
A472E4 Thermocouple, type-J, 5-1/2" length
A472E5 Thermocouple, type-J, 21-1/2" length
A472E6 Thermocouple, type-J, 15-1/2" length
A490E Dual T/C, type-J, 7-1/2" length
A490E2 Dual T/C, type-J, 9-1/2" length
A490E3 Dual T/C, type-J, 11-1/2" length
A490E4 Dual T/C, type-J, 5-1/2" length
A490E5 Dual T/C, type-J, 21-1/2" length
A490E6 Dual T/C, type-J, 15-1/2" length
A511E2 Heater T/C, type-J, bayonet style
A511E4 Heater T/C, dual, type-J, bayonet style
