7Installation
Final check
Once all the connections are made, turn the ignition on then off to perform the
installation test. The "Goodbye" message must be displayed.
If it is not the case, it is necessary to swap the positions of the red and yellow wires.
Indeed, the red wire of the power cable must be connected to the 12V ignition, the
yellow wire to the permanent 12V and the black wire to the ground. This can be
done simply by reversing both fuse holders located on the Parrot wiring.
Installing the cables
Connect the iPod / iPhone®, USB, Jack cables and the GPS Antenna to the Parrot
ASTEROID Classic. We recommend you connect all audio cables to the Parrot
ASTEROID Classic even if you do not plan on using them. Route the audio cables
to a suitable location in your vehicle such as the glove box or arm rest
compartment. It may be necessary to drill a hole in your dashboard to do so. Avoid
using USB extension cables.
Make sure you connect the iPod / iPhone cable to its specific USB port. "iPod" is
written above it.
Use the double-sided tape to stick the GPS Antenna to your dashboard. Once you
have stuck the dongle to the dashboard, wait for approximately 2 hours to make
sure the adhesive tape adheres well.
To guarantee an optimal reception quality we recommend you do not connect your
internet USB key 3G on the Parrot ASTEROID Classic directly : use the USB cable
to install your device on the dashboard (or any other open area).
Use the provided cable ties to make sure the cables are well fixed to the car stereo.
Insert one of the cable ties into the slot in the top left of the back of the car stereo
(refer to the diagram).
