7300w² Monitor Instruction Manual
6 System Configuration.
From the Measurement Display press to enter the “MAIN MENU”. From this menu, all
configurations and parameters are defined.
Setting up the monitor is a simple and intuitive process. The menu structure has been designed to lead
the operator through the configuration process. Simply start with the menu at the top and work down
through the menus.
Menu options are:
Monitor Config.
Expansion Config.
Sensor Config.
Measurement Config.
Alarm Config.
Output Config.
Information
Lock Config.
Press or to highlight the menu required, and press to select.
Press at any time to return back to the previous menu.
Note: If no key is pressed for 2 minutes, the monitor will default back to the measurement display
screen.
6.1 Monitor Config Menu
The MONITOR CONFIG menu is used to set up the core monitor
functions, including backlight, bleeper function, time and date. This main
menu option also provides access to some advanced configuration and
reset functions.
From the MAIN MENU, ensure MONITOR CONFIG is highlighted (if not,
press or to highlight the option) then press .
6.1.1 Bleeper
From the MONITOR CONFIG menu press or to select BLEEPER.
The bleeper (button pressed acknowledgement bleep) can be turned on
or off as desired. Under normal circumstances it is preferable to leave the
bleeper turned on as it provides an audible feedback of key presses and
a triple bleep is confirmation that a function has been successfully
changed or selected.
Press or to highlight the option required, and press to select. A
tick will appear next to your selection.
Press to exit this option.
224081IM Issue 22 Issue Date 27/03/2018 ` Page 19 of 46
