7300w² Monitor Instruction Manual
6.3.6 Default Modbus Addresses
Default Modbus
Address
Sensor / Expansion Box
0 Reserved for system – DO NOT USE
1 to 8 User Defined (advise: use for sensors)
9 User Defined (advise: use for Expansion Box)
10 OxyTechw² OPT
11 TurbiTechw² LS
12 TurbiTechw² LA
13 TurbiTechw² HR
14 TurbiTechw² LR (0-500)
15 TurbiTechw² LR (0-30)
16 OxyTechw² GAL
17 ColTechw² (0-200)
18 WaterTechw² pH8000
19 WaterTechw² Redox8000
20 WaterTechw² pHEVT
21 Expansion Box (8x 4-20mA, 8 Relay)
22 Expansion Box (4x 4-20mA, 4 Relay)
23 Expansion Box (4x 4-20mA, 4 Relay, 4 Input)
24 TurbiTechw² LR (0-30)
30 WaterTechw² C4E
33 OilTechw² FLT
37 OxyTechw² RDO Pro
38 OxyTechw² RDO Pro-X
39 Expansion Box (1x 4-20mA)
6.3.7 Measurement Config
The monitor leaves the factory without any configured measurements,
they can only be added after the relevant sensor(s) have been
recognised by the 7300w² Monitor by Sensor Configuration, see 6.3.
The Sensor will upload the available measurement parameters to the
7300w² Monitor and as they are registered the measurements will be
included in a list for the user to configure. A single sensor may only
provide a single measurement (e.g. Turbidity), or multiple measurements
(e.g. DO and Temperature). Each measurement may also be offered in
different formats (e.g. FTU or mg/l for Turbidity). All available
measurements and formats will be displayed under the Measurement Config Menu denoted by M01 to
M0x.
Further information on the configuration, operation and calibration of the measurements supplied by
our sensors are contained in the relevant manuals supplied with the sensor, please read both manuals
to ensure correct set up and operation.
6.3.8 Measurement Status
This option allows the user to review the current status of the 16
measurement channels. Configured measurements will show the type of
measurement and description and serial number of the sensor providing
the measurement. If a sensor is defective the measurement location will
display “S. Disconnected”. If only one measurement is configured, the
remaining fifteen measurement allocations will display “Disabled”.
Page 26 of 46 224081IM Issue 22 Issue Date 27/03/2018
MAIN MENU
Monitor Config
Expansion Config
Sensor Config
Measurement Config
Alarm Config
Output Config
Information
MEASUREMENT CONFIG
Measurement Status
Add Measurement
M:01 TurbiTech² LR NTU (S:01)
