Upgrading the hard drive
Refer to the following to remove and replace the hard drive.
Turn off the machine properly 1.
through the operating system.
Disconnect the power cord from 2.
the power outlet.
Remove the one screw3.
Pull out the hard drive tray.4.
Disconnect the power cable and 5.
IDE cable from the hard drive.
Remove the four screws, then 6.
remove the hard drive out from
the tray.
To replace the hard drive, reverse the above procedure.
