The transmission and interval settings you select are applied to all
the WITS codes in a record group.
Important:
For WITS devices connected to a toolpush connection box or
network panel, conflicts between transmission settings and the
EDR’s comm port settings can cause problems. For example, if
you select Request-Response, but the comm port is set to Send
Only, then the EDR will fail to receive the third party’s data, and it
will not respond.
Unit Use this drop-down to select the display units for the WITS value.
Data Summary Use this drop-down list to select how the EDR calculates the WITS
value.
Import and Export See Sending Gamma and Gamma Lag Calc
When sending Gamma (code 0824) and Gamma Lag
Calc (code 0821) data to the EDR, make sure you
meet these packet and frequency requirements:
• Send both codes in the same WITS
packet. Problems occur when Pason
receives one or the other, but not both.
• Send the packet at a minimum 0.2 m (1 ft)
interval.
A well-formed gamma packet looks like this:
&&
1984PASON/EDR
08211780.2
082463.8
!!
Importing and Exporting Your WITS Settings on page 30.
Factory Reset Clears all your selections and returns the settings to the defaults.
Table 1: WITS setup screen elements
In addition to choosing individual WITS codes, the EDR provides the option of using
preconfigured Full WITS or Half WITS settings to determine which WITS codes it sends.
