Pason WITS - Page 34

Revised May 1, 2019
Revision 25 of DOCU225, © Copyright
Page 34 of 44
Name
WITS
Code
EDR can
Receive
EDR Sends in
Full WITS
Mode
EDR Sends in
Half WITS
Mode
Available Transmission Types: Time Based, Depth Based, or Request-Response
Date 0805
Time
0806
Resistivity 1 Lag Calc 0813 Y Y
Resistivity 1
0816
Y
Y
Resistivity 2 Lag Calc
0817
Y
Y
Resistivity 2 0820 Y Y
Gamma Lag Calc
0821
Y
Y
Gamma
0824
Y
Y
Porosity 1 Lag Calc 0829 Y Y
Porosity 1 0831 Y Y
Porosity 2 Lag Calc
0832
Y
Y
Porosity 2 0834 Y Y
Formation Density Lag Cal
0839
Y
Y
Formation Density
0841
Y
Y
Record 09: MWD Mechanical
Available Transmission Types: Time Based, Depth Based, or Request-Response
Date 0905
Time 0906
Downhole Pressure 1 0913
Y
Y
Record 11: Mud Tank Volume
Available Transmission Types: Time Based, Depth Based, or Request-Response
Date
1105
Time
1106
Hole Depth
1108
Y
Total Mud Volume
1111
Y
Mud Tank 1 Volume
1115
Y
Mud Tank 2 Volume
1116
Y
Mud Tank 3 Volume 1117 Y
Mud Tank 4 Volume
1118
Y
Mud Tank 5 Volume
1119
Y
Mud Tank 6 Volume
1120
Y
Mud Tank 7 Volume
1121
Y
Mud Tank 8 Volume
1122
Y
Trip Tank Mud Volume
1129
Y
