Name
WITS
Code
EDR can
Receive
EDR Sends in
Full WITS
Mode
EDR Sends in
Half WITS
Mode
Record 12: Chromatograph Cycle Based
Available Transmission Types: Time Based, Depth Based, or Request-Response
Date 1205
Time 1206
chr Methane C1 1212
Y
Y
chr Ethane C2 1213
Y
Y
chr Propane C3 1214
Y
Y
chr Iso-Butane IC4 1215
Y
Y
chr Nor-Butane NC4 1216
Y
chr Iso-Pentane NC5 1217
Y
chr Nor-Pentane NC5 1218
Y
chr Neo-Pentane NC5 1219
Y
chr Iso-Hexane IC6 1220
Y
chr Nor-Hexane NC6 1221
Y
chr Carbon Dioxide CO2 1222
Y
chr Acetylene 1223
Y
chr Oxygen O2 1225
Y
chr Gas Specific GravityM 1226
Y
chr Total Gas 1229
Y
Y
Record 17: Cementing
Available Transmission Types: Time Based, Depth Based, or Request-Response
Cement Date 1705 Y
Cement Time
1706
Y
Y
Cement Pump Pressure
1712
Y
Y
Cement Slurry Rate
1716
Y
Y
Slurry Density
1719
Y
Y
Cement Fluid Temp
1722
Y
Y
Event Number
1724
Y
Y
Cement Stage Volume
1728
Y
Y
Cement Total Stage Volume
1730
Y
Y
Cement Water Rate 1734 Y Y
Annulus Pressure
1735
Y
Y
N2 Rate
1736
Y
Y
Cement Date
1745
Cement Time
1746
