PATON ProTIG AC/DC TIG/MMA - 14 -
Typical cyclogram of the 2-stroke button mode (TIG АС/2T+pulse)
Typical cyclogram of the 4-stroke button mode (TIG АС/4T+pulse)
Example of using the pulse mode:
Turn the machine on, switch to the TIG AC welding mode, set the basic parameters as
follows:
1. "BUTTON MODE" – button mode on the torch, 2Т.
2. "PREFLOW" – pre-purge time, 2 sec.
3. "START CURRENT" – start current, 30 A.
4. "RISE TIME" – current ramp up time, 1 sec.
5. "MAIN CURRENT" – main welding current, 100 A.
6. "FALL TIME" – current decay time, 1 sec.
7. "FINISH CURRENT" – completion current, 30 A.
8. "POSTFLOW" – post-purge time, 5 sec.
